1.Main Technical Parameter
Main machine power: 2.2KW(380V,50HZ)
Air motor power:0.9KW(380V,50HZ)
Rewinding speed:80-100 meters/min
Max diameter of finished roll(mm):1100mm
Outside dimension:1000x2400x1500mm(LxWxH)
Weight:about 1500-2000kg
2.Function and Feature
Air operated unwind with tension to suit different classes of raw paper.
Big cutter bar to cut, Strong knife-blade and easy turning without voice and shake.
Adopt vacuum to imbibe the edge of paper and keep Section in good order.The equipment is easy to repairand grind. |
