1.Function and Feature
Unwind with tension to suit different classes of raw paper.
Adopt screw turing knife to cut,Strong knife-blade and easy turning. Without voice and shake.
Controlled with electric counter to ensure weight of production.
The all steel roller rolling the pattern,the grain mark is Obvious.may select the rubber roller or the wool roller,the Serivce life is reliable.
Use special saw belt to keep section in good order.the saw belt is easy to repair and grind.
2.Main Technical Parameter
Electric power:3.0 KW (380V,50HZ)
Cuter power: 2.2 KW (380V,50HZ)
Rewinding speed:80-100 meters/min
Max diameter:1500mm
Machine size: 5100x2400x1500mm(LxWxH)
Weight: about 1500-2000kg |
